How to Persist Zenoh Data

June 22, 2026 · 9 min read

Co-founder & CEO - Data, ML & Robotics Systems

Persisting Zenoh data with ReductStore

If you're running Zenoh, whether as rmw_zenoh in ROS 2 or as the transport between a robot, a gateway, and the cloud, you'll eventually run into the same question:

"Where does this data actually go? I need to replay yesterday's run, debug a fault from a remote robot, and pull a few thousand frames for training."

There's plenty of material on the communication layer itself: pub/sub primitives, how Zenoh compares to DDS, multi-node setups down to a Raspberry Pi. rmw_zenoh reached Tier-1 status starting with ROS 2 Kilted Kaiju, and it's getting real attention at events like ROSCon.

What's harder to find is the next layer: what happens to a sample after it's published. Connecting a live Zenoh network to something persistent and queryable usually means working around the limits of Zenoh's existing storage options.

This post shows another way. By the end you'll have a Python publisher sending data over Zenoh, a storage backend persisting it automatically, and a query client pulling exact time ranges back out, all without a custom backend or a bridge process.

What the existing storage backends leave out

Zenoh ships official storage backends: memory, S3, InfluxDB, RocksDB, and filesystem via the zenoh-plugin-storage-manager. By default, queries return the latest stored value for each matching key. The InfluxDB backend goes further with a _time selector for historical queries:

robot/alpha/**?_time=[now(-5d)..now()]

That works for structured numeric telemetry. The problem is that InfluxDB stores binary payloads as base64-encoded strings, wildcard queries only work with v1.x, and sample attachments don't map to InfluxDB tags. The memory, RocksDB, filesystem, and S3 backends don't have a time-range query mechanism at all.

What was missing was a backend built for binary time-series data: one that stores every sample as-is, indexes it by time, and fits Zenoh's data model without a translation layer. That's what led to building a native Zenoh API in ReductStore.

A storage backend that speaks Zenoh natively

Starting with version 1.19, ReductStore (an open source time series object store built for robotics and edge data) ships a native Zenoh API. It keeps every sample, not just the latest, indexed by time, so the queries above just work. A ReductStore instance joins your Zenoh network as a regular peer: it registers a subscriber for writes and a queryable for reads, talking directly to the storage engine. No bridge process, no extra protocol, no custom backend to maintain.

The mapping between Zenoh and ReductStore's data model is close to one-to-one:

Zenoh sample	ReductStore record
Key	Entry name
Timestamp	Timestamp
Payload	Payload
Attachment	Labels

A Zenoh key like robot/alpha/camera becomes an entry in a bucket. The attachment, Zenoh's mechanism for attaching metadata to a sample, becomes a set of labels you can later filter on. Everything else (HTTP API, SDKs, web console, retention policies, replication) works on that same data, regardless of whether it arrived via Zenoh or HTTP.

Setting it up

The full runnable example, two simulated robots, a Zenoh router, ReductStore, and a query client, is on GitHub at reductstore/zenoh-example. Clone it and docker compose up if you want to follow along directly. Below is the minimal setup, piece by piece.

1. Run ReductStore as a Zenoh peer

The entire integration is configuration, with no code changes to ReductStore itself. Add this service to your docker-compose.yml:

services:
  zenoh-router:
    image: eclipse/zenoh:latest
    ports:
      - "7447:7447"

  reductstore:
    image: reduct/store:latest # v1.19+ has a native Zenoh API
    environment:
      RS_API_TOKEN: "reductstore"
      RS_BUCKET_0_NAME: "fleet"
      RS_BUCKET_0_QUOTA_TYPE: "FIFO"
      RS_BUCKET_0_QUOTA_SIZE: "1 GB"
      RS_ZENOH_ENABLED: "true"
      RS_ZENOH_CONFIG: "mode=client;connect/endpoints=[tcp/zenoh-router:7447]"
      RS_ZENOH_BUCKET: "fleet"
      RS_ZENOH_SUB_KEYEXPRS: "robot/**"
      RS_ZENOH_QUERY_KEYEXPRS: "robot/**"
      RS_ZENOH_QUERY_LOCALITY: "Any"
    ports:
      - "8383:8383"
    depends_on:
      - zenoh-router

RS_ZENOH_SUB_KEYEXPRS and RS_ZENOH_QUERY_KEYEXPRS are key expressions, wildcard patterns like robot/**, that define which keys ReductStore subscribes to and answers queries for. The fleet bucket is created automatically on startup, and the quota settings make it a rolling store that keeps the most recent 1 GB of data.

2. Publish from your ROS 2 / Zenoh node

Any node publishing on a matching key gets persisted automatically. No SDK calls, no extra client, just publish the way you already do, with timestamps and an optional attachment for metadata:

import json
import zenoh

ROBOT_ID = "alpha"
KEY = f"robot/{ROBOT_ID}/telemetry"

with zenoh.open(zenoh.Config()) as session:
    pub = session.declare_publisher(KEY)

    telemetry = {"battery": 87, "status": "ok", "speed": 1.2}
    labels = {"robot": ROBOT_ID, "status": telemetry["status"]}

    pub.put(
        json.dumps(telemetry).encode(),
        encoding=zenoh.Encoding.APPLICATION_JSON,
        attachment=json.dumps(labels).encode(),
    )

The JSON attachment becomes record labels in ReductStore. ReductStore also adds two labels automatically to every record: zenoh_source_id (which node published it, useful for tracing data provenance across a fleet) and zenoh_ts_ntp64 (the original Zenoh HLC timestamp at full precision).

3. Query a time range back out over Zenoh

This is the part that's usually missing: querying isn't bolted on as a separate HTTP step. It's the same Zenoh session, using get() with a selector that carries a time range:

import zenoh

KEY = "robot/alpha/telemetry"
start_us = 1_700_000_000_000_000
stop_us = 1_700_000_600_000_000

with zenoh.open(zenoh.Config()) as session:
    replies = session.get(
        f"{KEY}?start={start_us};stop={stop_us}",
        consolidation=zenoh.ConsolidationMode.NONE,
    )
    for reply in replies:
        if reply.ok:
            print(reply.ok.payload.to_bytes())

ConsolidationMode.NONE matters here: without it, Zenoh may consolidate replies down to a single sample per key. For a time-series query you want every record in the range, so consolidation has to be disabled.

4. Filter by label while you're at it

Because the JSON attachment becomes labels, you can filter server-side using the same conditional query language ReductStore's HTTP API uses, with no client-side filtering required:

import json
import zenoh

attachment = json.dumps({"when": {"&status": {"$eq": "warn"}}}).encode()

with zenoh.open(zenoh.Config()) as session:
    replies = session.get(
        f"robot/alpha/camera?start={start_us};stop={stop_us}",
        attachment=attachment,
        consolidation=zenoh.ConsolidationMode.NONE,
    )
    for reply in replies:
        if reply.ok:
            print(reply.ok.payload.to_bytes())

"Every camera frame from the last ten minutes where the robot was in a warn state" is one get() call. The when syntax supports comparison, logical, arithmetic, and aggregation operators. See the Conditional Query Reference for the full list.

5. Replay and inspect with the Python SDK

For replay, debugging, or building a training set, you don't have to stay on the Zenoh API. The same data is available over HTTP via the reduct-py SDK (or the JS, Go, Rust, and C++ SDKs):

import asyncio
from reduct import Client, BucketSettings, QuotaType

async def main():
    async with Client("http://localhost:8383", api_token="my-token") as client:
        bucket = await client.get_bucket("fleet")

        async for record in bucket.query(
            "robot/alpha/camera",
            start="2026-06-15T00:00:00Z",
            stop="2026-06-15T01:00:00Z",
            when={"&status": {"$eq": "warn"}},
        ):
            print(record.timestamp, record.size)
            frame = await record.read_all()
            # feed `frame` into your replay tool, notebook, or training pipeline

asyncio.run(main())

Live ingestion via Zenoh and historical queries via HTTP (or Zenoh) both read from the same bucket, so there's no separate export or sync step.

The same query works from anywhere on the network

This is Zenoh's location transparency at work: it routes a query to whoever answers for a key, so the same get() call works whether ReductStore is running next to the robot, on a gateway, or in the cloud:

# on the gateway
python query_zenoh.py --robot alpha --last 60

# from a laptop on a different network
python query_zenoh.py --robot alpha --last 60 \
    --endpoint tcp/gateway.example.com:7447

RS_ZENOH_QUERY_LOCALITY controls whether a given ReductStore instance answers local queries, remote queries, or both, useful if you want an edge instance to serve replay requests only from the robot itself, while a cloud instance serves everyone else.

Retention and replication, for free

Once data is flowing in, two problems show up fast: disks fill up, and you want a long-term copy of some of it in the cloud.

For retention, ReductStore buckets support a size-based FIFO quota: set a limit, and the oldest blocks are dropped to make room:

environment:
  RS_BUCKET_0_NAME: "fleet"
  RS_BUCKET_0_QUOTA_TYPE: "FIFO"
  RS_BUCKET_0_QUOTA_SIZE: "1 GB"

This is more robust at the edge than a time-based "keep the last 24 hours" policy: if a robot goes offline for a few days, a time-based rule would silently wipe everything by the time it reconnects. A size-based policy just keeps the most recent 1 GB, however long that takes to fill.

For replication, you can forward a filtered subset to a cloud instance using the same conditional query syntax, for example, only frames and telemetry around a "warn" event:

environment:
  RS_REPLICATION_1_NAME: "warn_to_cloud"
  RS_REPLICATION_1_SRC_BUCKET: "fleet"
  RS_REPLICATION_1_DST_BUCKET: "fleet"
  RS_REPLICATION_1_DST_HOST: "https://reduct.example-cloud.com"
  RS_REPLICATION_1_DST_TOKEN: "${CLOUD_TOKEN}"
  RS_REPLICATION_1_ENTRIES: "robot/*/camera,robot/*/telemetry"
  RS_REPLICATION_1_WHEN: '{"&status": {"$eq": "warn"}}'

The label you attach at ingest, status: warn, is the same label that drives the read query, the retention policy, and the replication rule. One concept, three jobs.

Try it yourself

The runnable version of everything above (two simulated robots, a router, ReductStore, and a query client) is on GitHub:

git clone https://github.com/reductstore/zenoh-example
cd zenoh-example
docker compose up --build

Once it's running, open the ReductStore web console at http://localhost:8383 (API token: reductstore) to browse the fleet bucket, inspect labels, and preview frames directly in the browser. From a separate terminal, query over Zenoh:

cd query && pip install -r requirements.txt

# latest 60 seconds of telemetry for robot alpha
python query_zenoh.py --robot alpha --last 60

# last 10 minutes, only records where status was "warn"
python query_zenoh.py --robot alpha --last 600 --only-warn

Next steps

If you're running rmw_zenoh in production or evaluating it for a fleet, the gap between "messages are flowing" and "I can replay, debug, and train on this data" is smaller than it looks. It's a Docker Compose service and a handful of environment variables, not a new component to build and maintain.

For the full configuration reference, including all RS_ZENOH_* settings, key expression syntax, and current limitations (single-bucket mode, no deletion via the Zenoh API), see the ReductStore Zenoh integration docs. For label-based filtering across queries, retention, and replication, see the Conditional Query Reference and the Data Replication guide.

If you have any questions or comments, feel free to use the ReductStore Community Forum.
