Continuous Ingest for ROS 2: No Splits, No Merge
A rosbag recording is ultimately written to files, and a single file cannot grow forever.
Something has to close it at some point, so rosbag2 makes you pick: ros2 bag record -a -b 100000
closes one every 100 kilobytes, or -d 9000 closes one every 9000 seconds. Either way, a
recording that runs for hours comes out as a directory of many small files instead of one huge
file that becomes awkward to work with.
Splitting a recording into five minute bags seems like a simple solution. The problem starts when you need to turn them back into one file.
A rosbag2 user reported that merging 300 GB of split recordings required roughly 600 GB of disk capacity. The original 300 GB stays on disk while another 300 GB is written out as the merged bag.
Splitting solves one problem. Merging creates another, and it is easy to underestimate.
Why the splits are usually small
Nothing forces the split down to five minutes specifically. Three practical limits push it there. A robot that loses power mid recording loses only the file that was open, so a smaller file loses less. A single file that grows for eight hours is awkward to copy off a machine. And many tools that read bags slow down or run out of memory on files above a few gigabytes.
None of that is wrong. Splitting does what it was asked to do. It just moves the work to the other end of the workflow: more files to manage, more disk needed to merge them, and more time before the recording is ready to use.
Two more problems with continuous recording
Splitting does not limit total disk usage. The size and duration limits on ros2 bag record
cap each bag, not the recording as a whole. It keeps creating new bags until the disk is full. On
an embedded robot, a full disk can cause seemingly unrelated services to fail because they can no
longer write logs, temporary files, databases or caches.
Frequent splitting can also get more expensive over time. An open report on rosbag2 shows CPU use increasing over time when bags are split frequently. The proposed fix points to metadata written on every split: it currently includes the growing list of all bag files recorded so far, making each split progressively more expensive.
Splitting solves the practical problem of keeping individual recordings manageable, but it does not solve retention. Every split also adds another file that has to be tracked and handled later. Fix the CPU issue and you still end up with a directory of files that represents one continuous recording.
Store each topic separately, as the messages arrive
The alternative is to store the data as it is. Messages can be stored separately per topic in the original format, rather than recording everything into one file.
Reduct Bridge subscribes to ROS 2 topics and writes each message as it arrives, keeping the payload as serialized CDR so nothing is re-encoded on the way in.
The schema is stored alongside the data, selected message fields can become labels, and the
timestamp can come from the message's own ros_stamp. That means the data keeps enough context to
decode, filter and query it later without changing the original CDR payload.
Writes are batched for efficiency, but a batch flush is not a split. Nothing downstream depends on that boundary. Once a record is written, it is addressed by timestamp rather than by which file contains it.
The bucket itself can be created with a FIFO quota by volume, which keeps recording within a fixed amount of disk space: you set a size limit on the bucket, the oldest records are deleted first, and the robot keeps recording.
There is no split, so there is no merge. The wider picture of what that changes on a fleet is in a database for robotics, and the retention and edge to cloud side is in how to store and manage robotics data.
What changes once recording is continuous
The robot now holds a rolling window of everything it recorded, bounded by the quota and indexed by time. The rest of the workflow follows from that: decide what leaves the machine, decide where it lands, then read it back.
You choose which data leaves the robot. A replication task copies records from the
bucket on the robot to a bucket in the cloud, and it takes a when condition on labels, so what
crosses the link is chosen rather than scheduled. It also carries context. Conditional
replication accepts #ctx_before and #ctx_after, each taking
a duration, and pulls in the records around every match. Label an anomaly on the way in, replicate
on that label with #ctx_before set to ten minutes, and what lands in the cloud is the incident
plus the ten minutes that led to it. With bags, the unit you can move is the file, and the file
was cut where the recorder decided, not where the incident was.
The robot keeps a plain filesystem, the cloud instance sits on object storage. On the robot, ReductStore writes to local disk, so recording carries on whether or not there is a network. What you replicate lands in a second instance in the cloud, which can use S3 or Azure Blob as its backend. The cloud instance keeps a local cache while older data is pushed to object storage. Neither end needs the recording cut into files first.
You ask the store a question instead of writing a script. Records are indexed by time, and labels filter within a range, so narrowing to one camera or one frame type happens in the query rather than in a pass over payloads.
For SQL queries, the CDR payload first has to be decoded. The ReductROS extension converts it to JSON on the way out, and ReductSelect runs the query over that, returning JSON, CSV or Parquet:
SELECT device_id, temperature FROM ENTRY() WHERE temperature > 20
Against a directory of bags, filtering by time or message fields means opening and processing the relevant files yourself.
Dashboards read the store directly. The Grafana data source pulls time series straight out of ReductStore buckets, so a stored topic becomes a panel without an export step in between. That matters most for the numeric topics riding alongside the heavy ones: battery voltage, motor temperature, CPU load, all recorded against the same clock as the camera frames. You can chart them, alert on them, and when something looks wrong, go to the images from the same moment because they share a timestamp. With bags, getting that data into a live dashboard requires another pipeline between the recordings and Grafana.
The bag becomes something you export, not something you record
Some tools still need a bag, and that is fine. ros2 bag play wants a directory with metadata in
it. Older Foxglove builds want a single file, since some versions cannot open several mcap files
at once, which is exactly why merging is tempting in the first place. Anything you have scripted
around loading bag files for analysis expects a path, not a
bucket.
You still get a bag when you need one. The ReductROS extension can export the topics and time range you ask for as mcap. Instead of recording an entire afternoon into bags just in case, the bag is created for the slice a tool actually needs.
What this does cost is worth being plain about. ReductROS is part of ReductStore Pro under a
commercial licence, so the export
path isn't the same kind of free as ros2 bag record. And the bridge is another process to
deploy on the robot, built against a sourced ROS 2 environment, where ros2 bag record is
already installed and needs no configuration to start.
Bags are still right for short, one off recordings
Record a bag for a prototype on the bench, a lab run, or a debug capture you will open once and throw away. Standing up a store and a bridge for that is more work than the recording is worth, and the tooling around bags is good.
Three ways to store ROS topics covers the middle ground, where the bag is still the recording unit but not the storage.
Conclusion
Splitting rosbag files makes sense for short recordings. But once recording becomes continuous, those file boundaries start getting in the way: you have to manage disk space, find which files contain the interval you want, and sometimes merge them again before you can use the data.
For long running robots, a time-indexed stream removes those file boundaries. The robot keeps a rolling window locally under a fixed storage limit, while selected data, such as an incident or the minutes around an anomaly, can be replicated to the cloud and stored on S3 or Azure Blob.
If a tool still needs a bag, export the topics and time range you need.
The bag remains useful for playback, exchange and analysis. It just no longer has to define how continuous data is recorded and stored.
The Reduct Bridge docs cover the ROS 2 input and what it writes, and the data querying guide covers reading an interval back out.
If you have any questions or comments, feel free to use the ReductStore Community Forum.
